Mile High RC's Exceptionally Valued  Electronic Speed Controllers & UBEC's





Dynam 18 Amp Brushless ESCDynam 18Amp ESC

Size(mm): 50 X 25 X 7
Weight: 21g
Current: 18A
NiCd/NiMh] /servos: 6/4 8/4 10/2
[Li-xx]/servos: 2/4 3/3


$12.00




Pentium 6 Amp ESC V4

             Download the Manual Here



Current: 6A Constant / 10A Burst

BEC Mode: Linear

BEC : 5v / .8A

Lipo Cells: 2 / NiMH : 5-6

Weight: 6g

Size: 24x12x6mm



Pentium 6 Amp ESC $10.00






Pentium 10 Amp ESC V4

             Download the Manual Here



Current: 10A Constant / 12A Burst

BEC Mode: Linear

BEC : 5v / 1A

Lipo Cells: 2-4 / NiMH : 5-12

Weight: 9.4g

Size: 38x18x6mm



Pentium 10 Amp ESC $12.80






Pentium 12 Amp ESC V4

             Download the Manual Here



Current: 12A Constant / 15A Burst

BEC Mode: Linear

BEC : 5v / 2A

Lipo Cells: 2-4 / NiMH : 5-12

Weight: 13g

Size: 32x24x10mm



Pentium 12 Amp ESC $13.00






Pentium 18A ESC V4

             Download the Manual Here



Current: 18A Constant / 22A Burst

BEC Mode: Linear

BEC : 5v / 2A

Lipo Cells: 2-4 / NiMH : 5-12

Weight: 19g

Size: 24x45x11mm



Pentium 18Amp ESC $18.00




Swift 20 Amp ESCSwift 20A ESC



             Download the Manual Here



Current: 20A Max

BEC Mode: Linear

BEC : 5v / 2A Max

Lipo Cells: 2-3

Weight: 19g

Size: 34x23x12mm



Swift 20 Amp ESC $21.00






HobbyWing 30A ESC V4

             Download the Manual Here

Current: 30A Constant / 40A Burst

BEC : 5v / 2A - Linear

Lipo Cells: 2-5 / NiMH : 5-15

Weight: 25g

Size: 24x45x11mm



HobbyWing FF 30Amp ESC $24.00










HobbyWing 40A ESC V4

             Download the Manual Here

Current: 40A Constant / 55A Burst

BEC Mode: Switching

BEC : 5v / 3A

Lipo Cells: 2-5 / NiMH : 5-15

Weight: 40g

Size: 55x28x15mm



HobbyWing 40Amp ESC $29.00






Swift 50A ESC

             Download the Manual Here

Current: 50A Max

BEC Mode: Linear

BEC : 5v / 2A Max

Lipo Cells: 2-4 / NiMH : 6-12

Weight: 38g

Size: 38x28x16mm



Swift 50Amp ESC $33.00








Hobby Wing 60A Brushless ESC

HobbyWing 60A ESC V4

             Download the Manual Here

Current: 60A Constant / 80A Burst

BEC Mode: Switching

BEC : 5v / 3A

Lipo Cells: 2-5 / NiMH : 5-15

Weight: 63g

Size: 56x28x18mm



HobbyWing 60Amp ESC $42.00






Hobby Wing plush 80A Brushless ESC

Pentium 80A ESC V4

Download the Manual Here

Current: 80A Constant / 100A Burst

BEC Mode: Switching

BEC : 5v / 3A

Lipo Cells: 2-6 / NiMH : 5-18

Weight: 62g

Size: 70x31x14mm



Pentium 80Amp ESC $49.00






Pentium 80A HV ESC V4

Download the Manual Here

Current: 80A Constant / 120A Burst

BEC : None

Lipo Cells: 5-10 / NiMH : 5-30

Weight: 4.4oz. (125g)

Size: 78x55x18mm



Pentium 80Amp ESC $67.00




120 Amp ESC

Platinum 120A HV Opto ESC V4

Download the Manual Here

Current: 120A Constant / 180A Burst

BEC : None

Lipo Cells: 5-12 / NiMH : 15-36

Weight: 4.4oz. (125g)

Size: 88x55x15mm



Platinum 120A HV Opto ESC $160.00






HobbyWing ESC Program Card



Note: This program card is NOT suitable for Platinum series airplane ESC.
Size:  92mm(L)X52mm(W)X6mm (H). Weight:  26g.
Input Voltage:  4.8-6V
      (If the ESC does not have a built-in BEC, use an additional battery to power the program card)



HobbyWing ESC Program Card $13.00














ZTW ESC's

ZTW is a new generation of brushless speed controllers. Its performance in terms of compatibility, reliability and stability is second to none and compares directly to any of the major brands in the market.

Features of the ZTW Line of Esc's:

Support High RPM motors, are fully programmable, incorporate power arming protection: (prevents the motor from accidentally running when switched ON), Lost Throttle signal protection: The ESC will automatically reduces output power to the motor when it detects a lost of throttle signal for 1 second. A subsequent loss of throttle signal beyond 3 seconds will cause the ESC automatically to cut power to the motor, Automatic safety thermal over-load protection: (Automatically reduce output power to half when the temperature reaches 110, restore output power when the temperature is below 110.), Acceleration: Provides quick acceleration start ups with a linear throttle response, Governor Mode: Helicopter application with latest software design, especially for all types of brushless motor.

Program Functions: (programed with ZTW Program Card), Brake: on/off (Factory default setting: off)

Battery type: LiPo /NiMh/NiCad (Factory default setting: 3Li-Poly)

Low voltage cutoff: (Factory default setting: Reduce power) Reduce power: Reduce motor speed to half throttle, Cut off: Stop motor immediately. Ignore: Motor won’t stop until battery totally gone, Not suggested for lipos)

Soft start (Acceleration): Factory default setting: Soft start: Enable

Timing: (Factory default setting: Automatic) Automatic: (7-30 degree) ~~ Soft: (7 -22 degree) ~~ Hard:( 22-30 degree)

Frequency : 8KHz/ 16 KHz, Factory default setting: 8KHz


ZTW 12 Amp Brushless ESC



Specs:

Can handle constant current of 12A with bursts of 16Amps

Input Voltage : 5-12 Metal Cells or 2-4 cell Lipos

BEC : 5V / 1A (1.5A Max)

Dimensions: 21mm x 22m x 4mm

Only 8g

Program via Radio or Optional Program Card



Great ESC for Foamies or models running up to 100 Watts. Other ESC's in this quality range retail for $29.95.  Our price $17.99 with 12 month material and workmanship warranty.



ZTW 12 Amp ESC $17.99

Out - of - Stock


ZTW 20 Amp Brushless ESC

Specs:

Can handle constant current of 20A with bursts of 30Amps

Input Voltage : 5-12 Metal Cells or 2-4 cell Lipos

BEC : 5V / 2A (3A Max)

Dimensions: 28mm x 28m x 8mm

Only 18g

Program via Radio or Optional Program Card



Great ESC for models running up to jus over 200 Watts. Other ESC's in this quality range retail for $39.95 up to almost $80.00.  Our price $20.80 with 12 month material and workmanship warranty.



ZTW 20 Amp ESC $20.80Out - of - Stock








ZTW 50 Amp Brushless ESC



Specs:

Can handle constant current of 50A with bursts of 70Amps

Input Voltage : 5-18 Metal Cells or 2-6 cell Lipos

SBEC : 5.5V / 4A (5A Max)

Dimensions: 23mm x 52m x 7mm

Only 32g

Program via Radio or Optional Program Card



Other ESC's in this quality range retail for $59.95 up to almost $100.00.  Our price $41.60 with 12 month material and workmanship warranty.



ZTW 50 Amp ESC $41.60



Out-of-Stock




ZTW 70 Amp Brushless ESC



Specs:

Can handle constant current of 70A with bursts of 90Amps

Input Voltage : 5-18 Metal Cells or 2-6 cell Lipos

SBEC : 5.5V / 4A (5A Max)

Dimensions: 23mm x 52m x 14mm

Only 48g

Program via Radio or Optional Program Card



Other ESC's in this quality range retail for almost $120.00.  Our price $51.20 with 12 month material and workmanship warranty.







ZTW 70 Amp ESC $51.20

They Sold out FAST!!!




ZTW 85 Amp Brushless ESC



Specs:

Can handle constant current of 85A with bursts of 100Amps

Input Voltage : 5-18 Metal Cells or 2-6 cell Lipos

SBEC : 5.5V / 5A (Unknown Max rating)

Dimensions: 34mm x 52m x 14mm

Only 70g

Program via Radio or Optional Program Card



Other ESC's in this quality range retail for around $140.00  Our price $69.10 with 12 month material and workmanship warranty. This is by far our favorite ESC, Combo it with the 4250-7 and 4 cell or better yet the 5055-8 on 5 cell lipo and enjoy 1000 watt power at your finger tips!!



ZTW 85 Amp ESC $69.10



Out-of-Stock




ZTW 100 Amp HV Opto Brushless ESC



Specs:

Can handle constant current of 100A with bursts of 120Amps

Input Voltage : 18-38 Metal Cells or 6-12 cell Lipos

SBEC : No BEC - see UBEC Below

Dimensions: 34mm x 55m x 20mm

Only 76g

Program via Radio or Optional Program Card



Other ESC's in this quality range retail for around $140.00  Our price $118.40 with 12 month material and workmanship warranty.



ZTW 100 Amp HV ESC $118.40

Out - of - Stock








ZTW 5V/6V UBEC



Specs:



Input Voltage : 5V - 25V

Output: Switch selctable 5V or 6V 3Amps - 5Amps Max





$9.00 with 12 month material and workmanship warranty.





ZTW 5V/6V UBEC $9.00














ZTW Program card for ZTW ESC's



The ZTW allows you to program your esc for many functions. Select the battery type, RMP limits, Start (normal, soft, or very soft), Brake, Timing (Auto, 7-22, 22-30), Rotation, LVC (2.8V per cell, 3V per cell, 3.2V per cell), and how the LVC is activated (total power cut to motor, or reduce RPM's with power to land).







$8.50 with 12 month material and workmanship warranty.





ZTW Program Card - $8.50Out - of - Stock










Videos below in a 72" Proto type 3DH 330SC Running ZTW 110A ESC @ Elevation




All Products are guaranteed to be free from manufactures defects and operate as stated. Please take advantage of our guarantee if you have any problems. We also like to know how our products stack up and how you like them, so after use please drop us a line with your flight impressions. The more we know the more we can help the next guy.
